HitLights Premium Luma5 EX LED Light Strip, Single Color (UL-Listed) 24.6 Feet - High Density [IP-30]

Luma5 EX 12V LED Strip Light High Density 24.6ft IP20 Indoor

SKU: L0512V-302-2330-U

1 review

Color: Warm White 3000K

Variant

Price:

$46.99

Quantity:

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

WHAT STANDS OUT

High-density, bright output – 900 SMD 2835 LEDs delivering about 300 lumens per foot for clean, even indoor lighting.
Color-true, professional quality – 90+ CRI, UL-listed, 60,000-hour lifetime and 6-year warranty for demanding projects.
Installer-friendly customization – 24.6 ft 12V strip, 10 mm wide, cuttable at marked 1" sections and compatible with HitLights 12V drivers and connectors.

PRODUCT DETAILS:

HitLights Premium Luma5 EX is a high density 12V LED strip light designed for smooth, continuous indoor accent lighting over a 24.6 foot run. This single color strip uses 900 SMD 2835 LEDs with a 90+ CRI, delivering even, accurate illumination for cabinets, shelving, display cases and coves. The UL-listed 10 mm tape and double-sided PCB construction support reliable performance in professional and commercial installations.

24.6 ft 12V single color LED strip, approx. 252–300 lumens per foot, 120° beam angle
High CRI 90+ for true-to-life colors on countertops, products and finishes
Cuttable in 1 inch sections for precise lengths and custom layouts
Rated 60,000 hour lifetime with a 6 year warranty for long term use

Running on 12V DC at 2.4 W per foot, a full 24.6 foot reel draws about 59 watts, making it easy to pair with standard HitLights 12V LED drivers and dimming solutions. When connected to compatible dimmable drivers or EZDim controls, the strip provides flexible brightness adjustment for both task lighting and ambient glow.

The Luma5 EX single color LED strip is offered in 3000K, 4000K and 5000K color temperatures, allowing installers to match warm, neutral or cool white light to surrounding finishes. Its IP30 rating and flexible tape format are intended for indoor, dry locations where clean, discreet linear lighting is required.

Unlike many standard LED strips with lower CRI and limited warranty coverage, this high density tape is engineered for consistent light quality, long service life and verified safety through UL listing. It suits contractors, electricians, millwork shops and advanced DIY users who need dependable single color LED strip lighting for built-ins, retail fixtures and residential upgrades.

WHAT'S INCLUDED:

1 × 24.6 ft HitLights Premium Luma5 EX 12V single color LED strip (high density, IP30, UL listed)
Pre-attached DC male and female connectors for easy connection to compatible 12V power supplies

Note: power supply, dimmer, controllers and mounting accessories are sold separately.

FREQUENTLY ASKED QUESTIONS:

Q: What is the HitLights Premium Luma5 EX 12V LED strip light?
A: The Premium Luma5 EX is a 24.6 ft single color, high density 12V LED strip light for indoor accent and task lighting. It uses 900 SMD 2835 LEDs on a 10 mm UL-listed tape with a 90+ CRI to deliver smooth, even illumination in cabinets, shelving, display cases and coves.

Q: Who is this LED strip best suited for and where is it typically used?
A: This strip is designed for contractors, electricians, fabricators and advanced DIY users installing built-in, under-cabinet, cove, retail or display lighting. The 24.6 ft length, high CRI and high density layout make it ideal for continuous runs in kitchens, living spaces, showcases and millwork projects where consistent light quality is important.

Q: Can this 12V LED strip be used outdoors or in damp locations?
A: No. The Premium Luma5 EX strip is rated IP30 and is intended for indoor, dry locations only. It should be installed away from moisture, splashes and weather exposure. For outdoor or wet-location projects, a separately rated weatherproof LED strip with a higher IP rating is required.

Q: How long is the strip and can it be cut to custom lengths?
A: Each reel provides 24.6 feet of flexible LED tape and can be cut in 1 inch sections at marked cut points. This allows installers to create precise custom lengths for cabinets, shelves and architectural details, then reconnect sections with compatible 10 mm single color LED strip connectors if needed.

Q: What are the main specifications of this LED strip?
A: The strip operates at 12V DC and uses 2.4 watts per foot, with approximately 252–300 lumens per foot and a 120° beam angle. It features 900 SMD 2835 LEDs per 24.6 ft reel, 90+ CRI, 3000K, 4000K or 5000K color options, IP30 indoor rating, UL listing, 60,000 hour rated life and a 6 year warranty.

Q: What power supply and dimmer should be used with this strip?
A: A full 24.6 ft reel draws about 59 watts at 12V DC, so it should be paired with a compatible 12V LED driver rated at or above that load, with additional headroom recommended. For dimming, HitLights LED dimmable drivers and EZDim controls are listed as compatible options, allowing smooth brightness adjustment when properly wired.

Q: What is included and how long is the warranty?
A: Each package includes one 24.6 ft Premium Luma5 EX 12V single color LED strip with DC connectors attached; power supplies and accessories are sold separately. The product is UL listed and backed by a 6 year warranty, reflecting a rated operating life of up to 60,000 hours under specified conditions.

SHIPPING DETAILS:

Standard Shipping (3-5 Days) - Shipping cutoff 3pm (PST).
FREE ground shipping (UPS or FedEx) on orders of $199 or more
Standard Shipping: Flat Rate $9.99 - Cutoff 3PM (PST)
2-Day Shipping: Rate Based on Weight - Cutoff 2PM (PST)
Overnight Shipping: Rate Based on Weight - Cutoff 2PM (PST)

LED Type: SMD 2835
Color Rending Index: 90+
CCT Range: 3000K, 4000K, 5000K
Beam Angle: 120 degrees
Waterproof Rating: IP30 indoor use only
Length: 24.6ft
Width: 10mm
Certification: UL Listed
Luminous Flux: 300 Lm/ft
Input Voltage: DC 12V
Power/feet: 2.4W/ft
Size of cut section: 1in
LEDs per section: 3 LEDs
Static Electricity: 2000V (ESD)
Warranty: 6 years
Lifetime: 60,000 hours lifetime for Tc<158℉

Certifications:

Can I put this be used outdoors?

No, since this is IP30 rated it is for indoor use only.

How long is the warranty?

The warranty of this unit is for 6 years.

Can I cut the lights?

Yes, the lights can be cut every 62.5mm or 2.5 inches for custom lengths where there is a cut mark

Is Premium Luma5 LED Light Strip dimmable?

You can dim the Premium Luma5 LED Light Strip using the HitLights LED Dimmable Driver or EZDim.

What if I receive a damaged item?

Please call us at 1 (855) 768-4135 or email us at customerservice@hitlights.com to be assisted.

How do I track an order?

Once your order has shipped you will receive an email confirming that your order has shipped. On this email is a tracking number. There will be a link in your email to either UPS or USPS. Click on this link and you will be able to track your order.

DATA SHEET

Luma 5 EX LED Strip Spec Sheet

CERTIFICATION

UL Listing IFDR.E362417
